General Specifications
AC Power Type
Note 1: Use in environments that satisfy product specifications.
Note 2: UL, c-UL Listed at 0 to +50°C (FT1A Version V110).
Note 3: Supports input/output overvoltage protection. When overvoltage protection occurred, the power supply output is shut off. In this situation,
shut off the AC input, wait for one minute or longer, and then turn on the AC input again.
Type Number
FT1A-
H12RC, B12RC H24RC, B24RC H40RC, B40RC
H48KC, H48SC
B48KC, B48SC
Normal Operating Conditions
Operating Temperature 0 to +55°C (operating ambient temperature) (Note 2)
Storage Temperature –25 to +70°C (no freezing)
Relative Humidity 10 to 95% (non-condensing, operating and storage humidity)
Pollution Degree 2 (IEC60664-1)
Degree of Protection IP20 (IEC60529)
Corrosion Immunity Atmosphere free from corrosive gases
Altitude
Operation: 0 to 2,000m (0 to 6,565 feet)
Transport: 0 to 3,000m (0 to 9,840 feet)
Installation Location Inside cabinet (Note 1)
Device Class Open equipment
Overvoltage Category II
Vibration Resistance
When mounted on a DIN rail or panel surface:
5 to 8.4Hz amplitude 3.5mm, 8.4 to 150Hz acceleration 9.8m/s
2
(1G)
2 hours per axis on each of three mutually perpendicular axes
Shock Resistance 147 m/s
2
(15G), 11ms duration, 3 shocks per axis on three mutually perpendicular axes
Power Supply (Note 3)
Rated Power Voltage 100 to 240V AC
Allowable Voltage Range 85 to 264V AC
Rated Power Frequency 50/60Hz (47 to 63Hz)
Maximum Power Consumption 18VA 41VA 48VA 43VA
Allowable Momentary Power Interruption 10ms maximum (at the rated power voltage)
Dielectric Strength Voltage
Between power and PE terminals: 1,500V AC, 1 minute
Between input and PE terminals: 1,500V AC, 1 minute
Between transistor output and PE terminals: 1,500V AC, 1 minute
Between relay output and PE terminals: 2,300V AC, 1 minute
Between power and input terminals: 1,500V AC, 1 minute
Between power and transistor output terminals: 1,500V AC, 1 minute
Between power and relay output terminals: 2,300V AC, 1 minute
Between input and transistor output terminals: 1,500V AC, 1 minute
Between input and relay output terminals: 2,300V AC, 1 minute
EMC Immunity IEC/EN 61131-2:2007 compliant
Inrush Current 35A maximum (Cold start with T
a
= 25°C, 200V AC)
Ground D-type ground (Class 3 ground)
Grounding Wire UL1007 AWG16
Power Supply Wire UL1015 AWG22, UL1007 AWG18
Effect of Improper Power Supply
Connection
Reverse polarity: Normal operation
Improper voltage or frequency: Permanent damage may be caused
Improper lead connection: Permanent damage may be caused
Weight Approx. 230g Approx. 400g Approx. 580g Approx. 540g
