IDEC FT1A Series User Manual

2: P RODUCT S PECIFICATIONS
2-8 S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378
LCD Specifications (SmartAXIS Pro only)
Input Specifications (AC Power Type)
Note 1: When an overload state occurs such as a short circuit in the input external power supply, the power supplied to the internal circuit of the
SmartAXIS is stopped. When the overload state is cleared, the output automatically recovers.
Description/Specifications
Type STN monochrome LCD
Resolution 64 x 192 pixels
Number of Characters
24 digits x 8 lines (8 x 8 pixel font)
12 digits x 8 lines (16 x 8 pixel font)
12 digits x 4 lines (16 x 16 pixel font)
Display Content System menus, messages, operation status monitor
Contrast Adjustment Not possible
Backlight Yes (backlight can be turned on and off)
Type Number
FT1A-
H12RC
B12RC
H24RC
B24RC
H40RC
B40RC
H48KC
H48SC
B48KC
B48SC
Input Points 8162430
Rated Input Voltage 24V DC
Input Voltage Range 0 to 28.8V DC
Terminal Arrangement See "Terminal Arrangement" on page 2-16.
Input External Power
Supply
Voltage Fluctuation
Range/Capacity (Note 1)
—
DC20.4 to 26.4V
250mA
DC20.4 to 26.4V
300mA
DC20.4 to 26.4V
300mA
Digital Input
Input Type Contacts Sink/Source
Input Points
(Terminal No./
Common Line Name)
8 points in 1 common line
(I0 to I7/COM)
16 points in 1 common
line
(I0 to I7, I10 to I17/COM)
24 points in 1 common
line
(I0 to I7, I10 to I17, I20
to I27/COM)
30 points in 2 common
lines
(I0 to I7, I10 to I17, I20
to I25/COMA, I26, I27,
I30 to I35/COMB)
Rated Input Current 5.3mA
Input Impedance 4.3k
Turn ON Time 40 s + filter value
Turn OFF Time 150 s + filter value
Isolation
Between input terminals: Not isolated
Internal circuit: Photocoupler isolated
Input Type Type 1 (IEC61131-2)
Shared Digital/Analog
Inputs
No
Status
Display
Pro LCD display
Lite —
External Load for I/O
Interconnection
Not needed
Signal Determination
Method
Static
Cable Length 100m in compliance with electromagnetic immunity
Effect of Improper
Input Connection
No damage. If any input exceeding the rated value is applied, permanent damage may be caused.

IDEC FT1A Series Specifications

General

Programming Software	WindLDR
Type	Programmable Logic Controller (PLC)
Display	LCD (varies by model)
Communication Ports	RS232C/RS485 (built-in), USB (programming), Ethernet (optional)
Dimensions	Varies by model
Weight	Varies by model
Model	FT1A Series
