S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 13-5
13: S CRIPTS
Script Manager
In the Script Manager dialog box, you can add scripts created in the Script Editor dialog box or delete registered scripts.
1. List of scripts
Shows the list of registered scripts.
2. Script
Shows the contents of the script selected in the Script list.
3. Add
Click this button to display the Script Editor dialog box in order to create and add a script.
For details, see "Script Editor" on page 13-6.
4. Edit
Click this button to open the Script Editor dialog box in order to edit the script selected in the Script List.
For details, see "Script Editor" on page 13-6.
5. Delete
Click this button to delete the script selected in the Script List.
6. Select
Click this button to close the Script Manager dialog box and set the script ID of the script selected in the Script List to the editing
dialog box.
7. Close
Click this button to close Script Manager.
Note: If you click Close when the script list was modified, a save confirmation message is displayed. Click Yes on the confirmation message to save
the changes. Click No to discard the changes and close Script Manager.
Script ID: Shows the script ID of the registered scripts (1 to 255).
Error: Shows OK if the registered script has no errors. Shows NG if there are any errors.
Script name: Shows the name of the registered scripts.
Used: Shows whether or not the registered scripts are used in this project.
1.
2.
3.
4.
5.
6. 7.
