IDEC FT1A Series User Manual

S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 14-11
14: T ROUBLESHOOTING
Troubleshooting Diagram 3
• SmartAXIS Lite - The Error Status LED (ERR) is On
Note: Temporary errors can be cleared to restore normal operation by clearing error codes from WindLDR. See "Clearing Error Codes from
WindLDR" on page 14-2.
The error status LED is on.
Clear error codes using WindLDR.
See Note below.
END
See "General Error Codes" on page 14-3.
Identify the error code and correct the error.
YES
Did the error status LED turn off?
NO
END
Call IDEC for assistance.
YES
Did the error status LED turn off?
NO

IDEC FT1A Series Specifications

General

Programming Software	WindLDR
Type	Programmable Logic Controller (PLC)
Display	LCD (varies by model)
Communication Ports	RS232C/RS485 (built-in), USB (programming), Ethernet (optional)
Dimensions	Varies by model
Weight	Varies by model
Model	FT1A Series
