IDEC FT1A Series User Manual

S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 14-13
14: T ROUBLESHOOTING
Troubleshooting Diagram 5
Does the monitored output
turn on and off?
NO
YES
YES
Call IDEC for assistance.
NOAre output device
addresses correct?
Correct the program.
The output circuit in the SmartAXIS is
damaged.
Replace the SmartAXIS.
END
Output does not operate normally.
SmartAXIS Lite: Check the output with WindLDR.
SmartAXIS Pro: Check the output with WindLDR
or the device monitor.
Click the Start button in WindLDR on a
computer connected to the SmartAXIS.
Note: The Start button is found in the
WindLDR menu bar.
NO
YES
SmartAXIS Lite:
Is the power/run status LED on?
SmartAXIS Pro:
Is the LCD backlight on?
Is the SmartAXIS output
connection correct?
NO
YES
Correctly connect the output.

IDEC FT1A Series Specifications

General

Programming Software	WindLDR
Type	Programmable Logic Controller (PLC)
Display	LCD (varies by model)
Communication Ports	RS232C/RS485 (built-in), USB (programming), Ethernet (optional)
Dimensions	Varies by model
Weight	Varies by model
Model	FT1A Series
