2: P RODUCT S PECIFICATIONS
2-32 S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378
FT1A-B24RA
*9.3mm when the clamp is pulled out.
FT1A-H24RC
*9.3mm when the clamp is pulled out.
FT1A-B24RC
*9.3mm when the clamp is pulled out.
100.0
2- Ø 4.5
90.0
119.0
110.3
11.05.0*
119.0
90.0
60.0
56.0
Direct Mounting Hole Layout
100.0
2-Ø
4.5
90.0
119.0
110.3
11.05.0*
119.0
90.0
78.0
74.0
Direct Mounting Hole Layout
100.0
2-Ø4.5
90.0
119.0
110.3
11.0
5.0*
119.0
90.0
78.0
74.0
Direct Mounting Hole Layout
