p.15iMDC-RIM BOARD
Process sta
tus LED
D7 Peer to Pe
er
Communic
ation Stat
us
LED
FLICKER It’s the LED to indicate Peer to Peer communication status bet
ween iMDC-MAINs. The LED flickers when communication be
tween iMDC-MAINs is processed.
D8 iMDC-MAI
N Setting
Status LED
FLICKER It’s the LED to indicate iMDC-MAIN function setting is possible
by STARWATCH ENTERPRISE.
D9 Event Savi
ng Status
LED
FLICKER It’s the LED to indicate event saving status happened in iMDC-
MAIN.
D10 iMDC-MAI
N Operati
ng
status LED
FLICKER It’s the LED to indicate iMDC-MAIN function operating status.
LED Code Normal St
atus
Description
5 iMDC-RIM BOARD
5.1 iMDC-RIM (Remote Interface Module) Board Configuration:
●
2ea Reader Ports
●
8ea Input Ports
●
8ea Output Ports (Relay Output)
