IDTECK iMDC-MAIN - IMDC-RIM Specification

SPECIFICATIONp.68
(Available to set output format)
Operating Temperature
0 ~ +65C (+32 ~ +149F)
Operating Humidity
10% ~ 90% Relative Humidity Non-condensing
Dimension (W x H x T)
137mm x 137mm x 18mm (5.4” x 5.4” x 0.75”)
Weight
148g (0.33lbs)
Certification
FCC, CE, KC
2 iMDC-RIM Specification
Model
iMDC-RIM
CPU
8Bit Micro Processor
Power / Current
DC +12V, Max.350mA
Memory Internal Memory
128 Kbyte Flash Memory
External Memory
4K SRAM
Reader
2ea
Input Port
8ea (Available to set input format)
Output Port
8ea (2 FORM-C Relay Output(COM, NO, NC)
/ DC +12V~ +18V, Rating Max. 2A)
Ethernet Speed
10/100 Mbps
LED Indicator
Status LED indicator
Operating Temperature
0 ~ +65C (+32 ~ +149F)
Operating Humidity
10% ~ 90% Relative humidity non-condensing
Dimension(W x T x T)
137mm x 137mm x 18mm (5.4” x 5.4” x 0.75”)
Weight
168g (0.37lbs)
Certification
FCC, CE, KC
