IDTECK iMDC-MAIN - Output; Event Output Number (32 Door: RIM 12 EA)

APPENDIXp.64
1.3 Output
L
Door Lock
A
Alarm
E
Etc
2 Event Output Number (32Door: RIM 12EA)
DOOR READER RIM OUTPUT INPUT
DOOR LOCK ALARM ETC EXIT CONTACT SENSOR
1 1 1 1 2 3 1 2 3
1 2 1 1 2 3 1 2 3
2 3 2 9 10 11 9 10 11
2 4 2 9 10 11 9 10 11
3 5 3 17 18 19 17 18 19
3 6 3 17 18 19 17 18 19
4 7 4 25 26 27 25 26 27
4 8 4 25 26 27 25 26 27
5 9 5 33 34 35 33 34 35
5 10 5 33 34 35 33 34 35
6 11 6 41 42 43 42 43 44
6 12 6 41 42 43 42 43 44
7 13 7 49 50 51 49 50 51
7 14 7 49 50 51 49 50 51
8 15 8 57 58 59 57 58 59
8 16 8 57 58 59 57 58 59
9 17 9 65 66 67 65 66 67
9 18 9 65 66 67 65 66 67
10 19 10 73 74 75 73 74 75
10 20 10 73 74 75 73 74 75
11 21 11 81 82 83 81 82 83
