p.65Event Output Number (32Door: RIM 12EA)
11 22 11 81 82 83 81 82 83
12 23 12 89 90 91 89 90 91
12 24 12 89 90 91 89 90 91
13 25 13 97 98 99 97 98 99
13 26 13 97 98 99 97 98 99
14 27 14 105 106 107 105 106 107
14 28 14 105 106 107 105 106 107
15 29 15 113 114 115 113 114 115
15 30 15 113 114 115 113 114 115
16 31 16 121 122 123 121 122 123
16 32 16 121 122 123 121 122 123
Default value of output time is 3 seconds.
DOOR LOCK
DOOR LOCK output number when access is granted.
ALARM
ALARM output number when alarm events occur.
ETC
Output number about other events
Ex) If a card is presented to reader #1, # 1 iMDC-RIM board output is activated. If t
he error occurs, output is activated to #2 output port of #1 iMDC-RIM board for 3
seconds.
