INSTALLATION TIPS & CHECK POINTSp.20
2 RECOMMENDED CABLE TYPE AND PERMISSIBLE LEN
GTH OF CABLE
Reference Description Cable specification Maximum distance
1 DC +12V → Power iMDC-MAIN
DC +12V → Power iMDC-RIM
Belden #9409, 18 AWG
2 conductor, unshielded
3m
*2
1
Reader (Power and Data)
Reader → iMDC-RIM
Belden #9512, 22 AWG
4 conductor, shielded
150m
Belden #9514, 22 AWG
8 conductor, shielded
3 Door Contact
Exit Button
Sensor Input
Input → iMDC-RIM
Belden #9512, 22 AWG
4 conductor, shielded
300m
Belden #9514, 22 AWG
8 conductor, shielded
4 Door Lock, Alarm Device
Lock (Alarm) → iMDC-RIM
Belden #9409, 18AWG
2 conductor, unshielded
300m
5 iMDC Cable
iMDC-RIM Cable
iMDC-MAIN ↔ iMDC-MAIN
iMDC-MAIN ↔ iMDC-RIM
iMDC-MAIN ↔ Host P.C
UTP Cable CAT5(Catagory5) 100m
~
150m
3 CHECK POINT DURING INSTALLATION
3.1 REVERSE DIODE CONNECTION
If you connect an inductor (Door Locks or Alarm device) to the output relays, there will be a
high surge voltage created while the inductor is turning on and off. To protect this problem,
connect the reverse diode as the figure below.
1 You need thicker wire if you connect the reader with high current consumption
