p.21CHECK POINT DURING INSTALLATION
It is strongly recommended to add a reverse diode between the inductor coils to a
bsorb this surge voltage. If you do not connect a reverse diode, the surge voltage
will transfer and damage the electronic circuit of the controller. 1N4004 – 1N4007
or equality efficiency diode is included in gift box.
