IDTECK iMDC-MAIN - Wiring; IMDC WIRING CONFIGURATION

WIRING
5
p.25
Wiring must be done before main power switched on to the iMDC-RIM. Wiring aft
er main power switched on may cause electrical shock.
1 iMDC WIRING CONFIGURATION
The figure below is basic installation configuration for iMDC-MAIN and iMDC-RIM. Wire iM
DC as the configuration below.
No. Code
