IDTECK iMDC-MAIN - Page 23

p.17iMDC-RIM BOARD
10 Relay Output #
7 Port
11 Relay Output #
8 Port
12 TTL Input #1 P
ort
It’s the ports to accept TTL input.
13 TTL Input #2 P
ort
14 TTL Input #3 P
ort
15 TTL Input #4 P
ort
16 TTL Input #5 P
ort
17 TTL Input #6 P
ort
18 TTL Input #7 P
ort
19 TTL Input #8 P
ort
20 Power Port It’s the port to accept power source.
iMDC uses DC +12V, Max.350mA current.
(When external devices such as door lock, alarm, sensor and reade
r are not connected.)
21 Mac Address S
ticker
It’s the sticker to indicate Mac address.
22 RJ45 It’s the Ethernet connection port to perform communication betw
een iMDC-MAIN and Host PC, iMDC-MAIN and the other iMDC-M
AINs, iMDC-MAIN and iMDC-RIM.
23 Power Status L
ED
Connector
It’s the connector to be connected to enclosure using cable. If red
LED is turned on, it means power has properly supplied.
24 Communicatio
n Status
LED Connector
It’s the connector to be connected to enclosure using cable. Green
LED indicates status of Ethernet communication.
25 Communicatio
n Status
LED Connector
It’s the connector to be connected to enclosure using cable. If com
munication between iMDC-MAIN and iMDC-RIM starts, the yellow
LED turns on.
26 Reset Switch It’s the reset switch to reboot the device. The set information main
No. Code Description
