page 141

Description

The function TDM_REPORT_KEYDATA can be polled

cyclically. It transfers the current key and LED status.

TA0 ... TA7 provide the key/LED status in bytes (e.g. bit-

oriented). With CTRL you select the key/LED groups to be

polled.

For the individual values please refer to the tdm R 360 manual.

CTRL always returns the value 0 when

TDM_CONTROL_STATUS_REPORT is switched on.
