Annex 1
. Address allocation ecomat R 360
Annex 1.1. Complete overview
Address Symbol Description
%IX0.00-%IX0.07 - Inputs (byte %IB0, word %IW0)
%IX0.08-%IX0.15 - Inputs (byte %IB1, word %IW0)
%IX0.16-%IX0.23 - Inputs (byte %IB2, word %IW1)
%IX0.24-%IX0.31 - Inputs (byte %IB3, word %IW1)
%IX0.32-%IX0.39 - Inputs (byte %IB4; word %IW2)
%QX0.00-%QX0.07 - Outputs (byte %QB0, word %QW0)
%QX0.08-%QX0.15 - Outputs (byte %QB1, word %QW0)
%QW0 - Outputs (byte %QB2, word %QW1)
%IB0 I0 Input byte 0
%IB1 I1 Input byte 1
%IB2 I2 Input byte 2
%IB3 I3 Input byte 3
%IB4 I4 Input byte 4
%QB0 Q1Q2 Output byte 0
%QB1 Q3 Output byte 1
%QB2 Q4 Output byte 2
%IW9 ANALOG0 Analog input 0
%IW10 ANALOG1 Analog input 1
%IW11 ANALOG2 Analog input 2
%IW12 ANALOG3 Analog input 3
%IW13 ANALOG4 Analog input 4
%IW14 ANALOG5 Analog input 5
%IW15 ANALOG6 Analog input 6
%IW16 ANALOG7 Analog input 7
Flag bit* RELAIS Relay bit
Flag bit* ERROR Set error bit
Flag bit* TEST Release programming mode (FALSE)
Flag bit* SERIAL_MODE Switch on serial communication (FALSE)
Flag bit* CAN_OPEN Switch on CANopen mode (FALSE)
Flag bit* ISO_DIRECTION Transmit or receive data (FALSE)
Flag bit* ERROR_MEMORY Memory error
Flag bit* ERROR_POWER Under/overvoltage error
Flag bit* ERROR_TEMPERATUR Excess temperature error (> 85°C)
Flag bit* CAN_ERROR CAN-Bus error (collective error bit)
Flag bit* CAN_INIT_ERROR CAN initialisation error
Flag bit* CAN_BUS_OFF_ERROR CAN-Bus off error
Flag bit* CAN_DATA_ERROR CAN-Data error
Flag bit* CAN_TX_OVERRUN_ERROR CAN-TX-Overrun error
Flag bit* CAN_RX_OVERRUN_ERROR CAN-RX-Overrun error
Flag bit* COP_SYNCFAIL_ERROR SYNC object missing
Flag bit* COP_GUARDFAIL_ERROR Guarding object missing
Flag byte* COP_GUARDFAIL_NODEID Number of missing CANopen slave
Flag bit* COP_PREOPERATIONAL CANopen mode preoperational
Flag bit* COP_PRESYNC Presync flag
Flag bit* COP_SYNC Sync flag
Flag bit* COP_EVENT_RESETCOM Communication reset triggered by the master
Flag bit* COP_EVENT_RESETNODE Node reset triggered by the master
Flag bit* COP_GUARDING_AGAIN Restart Node-Guarding after Reset-Node
Merkerword* CANBAUDRATE Currently set CAN-baud rate
Merkerbyte* NODEID Currently set node number
