page 148
Address Symbol Description
Flag bit* TEXT_MODE CAN communication compact display (FALSE)
Flag bit* TEXT_KEY_F1 Function key F1 compact display
Flag bit* TEXT_KEY_F2 Function key F2 compact display
Flag bit* TEXT_KEY_F3 Function key F3 compact display
Flag bit* TEXT_KEY_ESC ESC key compact display
Flag bit* TEXT_KEY_LEFT Key arrow-LEFT compact display
Flag bit* TEXT_KEY_RIGHT Key arrow-RIGHT compact display
Flag bit* TEXT_KEY_DOWN Key arrow-DOWN compact display
Flag bit* TEXT_KEY_UP Key arrow-UP compact display
Flag bit* TEXT_KEY_ENTER ENTER key compact display
Flag bit* TEXT_LED_F1 LED function key F1 compact display
Flag bit* TEXT_LED_F2 LED function key F1 compact display
Flag bit* TEXT_LED_F3 LED function key F1 compact display
%IB6 SHORT_Q1Q2_NEW Short circuit, output byte Q1Q2 (new)
%IB7 SHORT_Q3_NEW Short circuit, output byte Q3 (new)
%IB8 SHORT_Q4_NEW Short circuit, output byte Q4 (new)
%IB12 SHORT_Q1Q2_OLD Short circuit, output byte Q1Q2 (1 cycle old)
%IB13 SHORT_Q3_OLD Short circuit, output byte Q3 (1 cycle old)
%IB14 SHORT_Q4_OLD Short circuit, output byte Q4 (1 cycle old)
%IB9 BREAK_Q1Q2_NEW Wire break, output byte Q1Q2 (new)
%IB10 BREAK_Q3_NEW Wire break, output byte Q3 (new)
%IB11 BREAK_Q4_NEW Wire break, output byte Q4 (new)
%IB15 BREAK_Q1Q2_OLD Wire break, output byte Q1Q2 (1 cycle old)
%IB16 BREAK_Q3_OLD Wire break, output byte Q3 (1 cycle old)
%IB17 BREAK_Q4_OLD Wire break, output byte Q4 (1 cycle old)
* = Addresses might change depending on the controller configuration!
