IFM ecomat 100 R 360 Series User Manual

page 143
Function
TDM_SINGLE_LED_ON_OFF
Library TDM.LIB
Function symbol
Purpose
The function activates or deactivates a single tdm LED.
Parameter
Function inputs
Function outputs, none
Description
TDM_SINGLE_LED_ON_OFF can switch an individual LED on
(ON=TRUE) or off (ON=FALSE).
As opposed to the function TDM_LED,
TDM_SINGLE_LED_ON_OFF can be set permanently. The
corresponding CAN command is only transferred once within
the function thus preventing an excess workload on the CAN
bus.
For the individual values please refer to the tdm R 360 manual.
Name Data type Description
ENABLE BOOL TRUE: function is executed
FALSE: function is not executed
ON BOOL TRUE: LED switched on
FALSE: LED switched off
NUMBER BYTE individual LED number
