page 142
Function
TDM_LED
Library TDM.LIB
Function symbol
Purpose
The function activates or deactivates the tdm LEDs.
Parameter
Function inputs
Function outputs, none
Description
The function TDM_LED can be polled cyclically. This function
changes the status of the keyboard LEDs (set/reset). Depending
on the defined control parameters the LEDs can be processed
individually or bit-wise in groups of 8 via a mask value.
For the individual values please refer to the tdm R 360 manual.
Name Data type Description
ENABLE BOOL TRUE: function is executed
FALSE: function is not executed
CONTROL BYTE control parameter for setting / resetting
the LEDs
NUMBER BYTE LED mask number or individual LED
number
VALUE BYTE mask value when NUMBER = LED
mask number
