Index S-Idx Name Type Default Description
1603 0 Mapping Receive PDO 4 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0x5830 01 in 5830 SIdx 01, 1
st
word
received data RX PDO 4
2 Index in
object directory
u32 ro 0x5830 02 in 5830 SIdx 02, 2
nd
word
received data RX PDO 4
3 Index in
object directory
u32 ro 0x5830 03 in 5830 SIdx 03, 3
rd
word
received data RX PDO 4
4 Index in
object directory
u32 ro 0x5830 04 in 5830 SIdx 04, 4th word
received data RX PDO 4
1604 0 Mapping Receive PDO 5 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0x5840 01 in 5840 SIdx 01, 1
st
word
received data RX PDO 5
2 Index in
object directory
u32 ro 0x5840 02 in 5840 SIdx 02, 2
nd
word
received data RX PDO 5
3 Index in
object directory
u32 ro 0x5840 03 in 5840 SIdx 03, 3
rd
word
received data RX PDO 5
4 Index in
object directory
u32 ro 0x5840 04 in 5840 SIdx 04, 4
th
word
received data RX PDO 5
1605 0 Mapping Receive PDO 6 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0x5850 01 in 5850 SIdx 01, 1
st
word
received data RX PDO 6
2 Index in
object directory
u32 ro 0x5850 02 in 5850 SIdx 02, 2
nd
word
received data RX PDO 6
3 Index in
object directory
u32 ro 0x5850 03 in 5850 SIdx 03, 3rd word
received data RX PDO 6
4 Index in
object directory
u32 ro 0x5850 04 in 5850 SIdx 04, 4
th
word
received data RX PDO 6
1606 0 Mapping Receive PDO 7 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0x5860 01 in 5860 SIdx 01, 1
st
word
received data RX PDO 7
2 Index in
object directory
u32 ro 0x5860 02 in 5860 SIdx 02, 2
nd
word
received data RX PDO 7
3 Index in
object directory
u32 ro 0x5860 03 in 5860 SIdx 03, 3
rd
word
received data RX PDO 7
4 Index in
object directory
u32 ro 0x5860 04 in 5860 SIdx 04, 4
th
word
received data RX PDO 7
1607 0 Mapping Receive PDO 8 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0x5870 01 in 5870 SIdx 01, 1
st
word
received data RX PDO 8
2 Index in
object directory
u32 ro 0x5870 02 in 5870 SIdx 02, 2
nd
word
received data RX PDO 8
3 Index in
object directory
u32 ro 0x5870 03 in 5870 SIdx 03, 3
rd
word
received data RX PDO 8
4 Index in
object directory
u32 ro 0x5870 04 in 5870 SIdx 04, 4
th
word
received data RX PDO 8
