10.3.14 Ethernet Card Settings Command Wait Times

IP Mode

Command

Wait Time After Command is

Sent*

Manual

SIA, SGA, SSM

8 seconds

SIM 0

14 seconds

Auto

SDN

14 seconds

SIM 1

8 seconds

*Wait times are approximate and can vary based on the user’s network.
