4.4 Using Memories and Steps (PROGRAM Mode only)
4.4.1 Selecting a Memory
When in the Set screen use the soft keys <more> or <top> to navigate so the first
soft key shows Memory.
Now press the Memory soft key and you will see the following screen:
Memory = will show you the current memory that is active.
Name = will list the name of the memory location. If a name hasn’t been
programmed for the memory location this will be blank as shown above.
The Memory Range: indicates the valid range you can select for this parameter
screen. You can select 1 through 50 memory locations.
Two methods are available in selecting a memory.
1. Type in the memory number from the numeric keypad. Once you type in a
number a shaded black box (■) will begin blinking acknowledging the parameter
is being changed. You will also receive new text at the bottom of the display
“Enter to save, Esc to cancel”. To accept the data entry select the Enter soft key,
or to cancel the data entry select the Esc soft key.
