IKONIX apt 400XAC Series User Manual

114
OF X
OC Fold X
X=0~1, 0=OFF,1=ON
OF?
OC Fold?
0~1
SD X
TRANSIENT X
X=0~1,0=OFF,1=ON
SD?
TRANSIENT?
0~1
LOCK X
LOCK X
X=0~1, 0=OFF,1=ON
LOCK?
LOCK?
0-1
MEMLOCK X
MEMLOCK X
X=0~1, 0=OFF,1=ON
MEMLOCK?
MEMLOCK?
0-1
VS X
VOLT SENSE
X
X=0~1, 0=INT,1=EXT
VS?
VOLT SENSE?
0~1
FUNCTION X
FUNCTION X
X=0~2, 0=1Ø2W, 1=3Ø4W, 2=1Ø3W
FUNCTION?
FUNCTION?
0~2
SSI X
SYNC SIGNAL
X
X=0~2, 0=OFF,1=START,2=EVEN
X=0~2, 0=OFF,1=START,2=EVENT
SSI?
SYNC
SIGNAL?
0~2
0~2
8.4.6 IEEE 488.2 Common Commands
These commands are required by the IEEE-488.2 standard with the exception of
*PSC, *PSC?. Most of these commands are not available over the USB/RS-232
bus except for the *IDN? command which can be used to retrieve the instrument
identification information, and the four status reporting commands *ESR?, *ESE,
*ESE? and *STB?.
Command
Name
Description
*IDN?
Identification Query
Company, Model Number, Serial
Number, Firmware Revision
*RST
Reset Command
Resets Unit
*TST?
Self-Test Query
00H=OK
01H=TEST EEPROM ERROR
*CLS
Clear Status Command
Clear Standard Event Status
Register Clear Service Request
Register
