3. Specifications and Controls
3.1 Specifications
INPUT
430XAC
460XAC
Phase
1Ø
1Ø or 3Ø
Voltage
200~240 Vac ± 10%
1Ø : 200~240 Vac ± 10%
3Ø3W : 200~240 Vac ± 10%
3Ø4W : 346~416 Vac ± 10%
Frequency
47 - 63 Hz
AC OUTPUT
Power rating
1Ø2W
3000VA
6000VA
1Ø3W
Total 2000VA (1000VA per phase)
Total 4000VA (2000VA per phase)
3Ø4W
Total 3000VA (1000VA per phase)
Total 6000VA (2000VA per phase)
DC
3000VA
6000VA
Max.Current(r.m.s)
1Ø2W
5~150V
27.6A at <110V
55.2A at <110V
5~300V
13.8A at <220V
27.6A at <220V
1Ø3W
5~150V
9.2A at <110V for per phase
18.4A at <110V for per phase
5~300V
4.6A at <220V for per phase
9.2A at <220V for per phase
3Ø4W
5~150V
9.2A at <110V for per phase
18.4A at <110V for per phase
5~300V
4.6A at <220V for per phase
9.2A at <220V for per phase
Inrush Current
(peak) (*1)
1Ø2W
5~150V
110.4A
220.8A
5~300V
55.2A
110.4A
1Ø3W
5~150V
36.8A for per phase
73.6A for per phase
5~300V
18.4A for per phase
36.8A for per phase
3Ø4W
5~150V
36.8A for per phase
73.6A for per phase
5~300V
18.4A for per phase
36.8A for per phase
Phase
1Ø2W、1Ø3W、3Ø4W, provided option
THD(Total Harmonic Distortion)
<0.5% (Resistive Load) at 40.0~70.0Hz and output voltage within the 80~140Vac at
Low Range or the 160~280Vac at High Range.
<1% (Resistive Load) at 70.1~1000Hz and output voltage within the 80~140Vac at
Low Range or the 160~280Vac at High Range.
Crest Factor
≧3
Line Regulation
±0.1V
Load Regulation (Hardware) (*2)
± (1% of output +1V) at Resistive Load , < 400µS response time
Load Regulation (Software) (*2)
±0.2V,<1S response time
