IKONIX apt 400XAC Series User Manual

16
DC offset
≦±5mV
Voltage(*3)
Range
5~300 VAC (phase), 8.6~520 VAC (line), 150/300V Auto Range
Resolution
0.1V
Accuracy
±(0.2% of setting + 3counts)
Frequency
Range
40~1000Hz Full Range Adjust
Resolution
0.1Hz at 40.0~99.9Hz , 1Hz at 100~1000Hz
Accuracy
±0.03% of setting
Starting & Ending
Phase Angle
Range
0~359∘
Resolution
1∘
Accuracy
±1∘(45~65HZ)
Current Hi Limit
(OC Fold=OFF)
OC Fold Back
(OC Fold =
ON)(*10)
0V~150V
0.01~9.20A
0.01~18.40A
0V~300V
0.01~4.60A
0.01~9.20A
Resolution
0.01 Amps
Accuracy
± (2.0% of setting + 2 counts)
OC Fold Back Response Time
< 1.4S
Ramp-Up Timer
(second) (*4)
Range
0.0~999.9s
Resolution
0.1s
Accuracy
± (0.1% + 0.05 sec)
Ramp-Down
Timer (second)
(*4)
Range
0.0~999.9s
Resolution
0.1s
Accuracy
± (0.1% + 0.05 sec)
Delay Timer (*4)
Range
1s~999.9s
0.1m~999.9m
0.1h~999.9h
Resolution
0.1(s,m,h)
Accuracy
± (0.1% + 0.1 sec)
Dwell Timer (*4)
Range
0, 1s~999.9h (0=continuous)
Resolution
0.1(s,m,h)
Accuracy
± (0.1% + 0.1 sec)
Poly-phase
mode(3Ø4W) for
per phase
measurement
Frequency
Range
0.0-1000Hz
Resolution
0.1Hz
Accuracy
±0.1Hz (501-1000Hz Accuracy ±0.2Hz)
Voltage
Range
0.0-420.0V
