IKONIX apt 400XAC Series User Manual

17
Resolution
0.1V
Accuracy
± (0.2% of reading + 3counts)
Current(r.m.s) (*5)
Range
L
0.005A~1.200A
0.005A~2.400A
H
1.00A~13.00A
2.00A~26.00A
Resolution
L
0.001A
H
0.01A
Accuracy
L
± (1% of reading +5counts) at 40.0-500Hz
± (1% of reading +5counts) at 501-1000Hz and
CF<1.5
※Current (peak)≦3.6A
± (1% of reading +5counts) at 40.0-
500Hz
± (1% of reading +5counts) at 501-
1000Hz and CF<1.5
※Current (peak)≦7.2A
H
± (1% of reading +5counts) at 40.0-500Hz
± (1% of reading +5counts) at 501-1000Hz and
CF<1.5
※Current (peak)≦27.6A
± (1% of reading +5counts) at 40.0-
500Hz
± (1% of reading +5counts) at 501-
1000Hz and CF<1.5
※Current (peak)≦55.2A
Current(peak) (*5)
Range
0.0A~38.0A
0.0A~76.0A
Resolution
0.1A
Accuracy
± (1% of reading + 5counts) at 40.0-70.0Hz
± (1.5% of reading + 10counts) at 70.1 - 500Hz
± (1.5% of reading + 10counts) at 501 - 1000Hz and CF<1.5
Power (*5)
Range
L
0.0W~120.0W
0.0W~240.0W
H
100W~1300W
200W~2600W
Resolution
L
0.1W
H
1W
Accuracy
L
± (2% of reading +15 counts) at 40.0-500Hz and PF>=0.2
± (2% of reading +30 counts) at 501-1000Hz and PF>=0.5
H
± (2% of reading +5 counts) at 40.0-500Hz and PF>=0.2
± (2% of reading +15 counts) at 501-1000Hz and PF>=0.5
Power Factor
Range
0 - 1.000
Resolution
0.001
Calculated
Formula
W / VA
Power Apparent
(VA)
Range
(*15)
L
0.0VA~120.0VA
0.0VA~240.0VA
H
100VA~1300VA
200VA~2600VA
Resolution
L
0.1VA
H
1VA
