Calculated
Formula
V×A
Power Reactive
(Q) (*13)
Range
(*15)
L
0.0VAR~±120.0VAR
0.0VAR~±240.0VAR
H
0VAR~±1300VAR
0VAR~±2600VAR
Resolution
L
0.1VAR
H
1VAR
Calculated
Formula
(*14)
Crest Factor
Range
0 - 10.00
Resolution
0.01
Calculated
Formula
Ap / A
Poly-phase
mode(3Ø4W) for
Σ measurement
Frequency
Range
0.0-1000.0Hz
Resolution
0.1Hz
Accuracy
±0.1Hz (501-1000Hz Accuracy ±0.2Hz)
Voltage
Range
0.0-727.5V
Resolution
0.1V
Calculated Formula
(A+B+C)/√3
Current(r.m.s)
Range(*15)
L
0.005A~1.200A
0.005A~2.400A
H
1.00A~13.00A
2.00A~26.00A
Resolution
L
0.001A
H
0.01A
Calculated
Formula
L
H
Current(peak)
Range
N/A
Resolution
Accuracy
Power
Range(*15)
L
0.0W~360.0W
0.0W~720.0W
H
300W~3900W
600W~7800W
Resolution
L
0.1W
H
1W
Calculated
Formula
L
A Power + B Power + C Power
H
Power Factor
Range
0 - 1.000
Resolution
0.001
Calculated Formula
∑ W / ∑ VA
