IKONIX apt 400XAC Series User Manual

19
Power Apparent
(VA)
Range
(*15)
L
0.0VA~360.0VA
0.0VA~720.0VA
H
300VA~3900VA
600VA~7800VA
Resolution
L
0.1VA
H
1VA
Calculated
Formula
L
H
Power Reactive
(Q)
Range(*15
)
L
0.0VAR~360.0VAR
0.0VAR~720.0VAR
H
300VAR~3900VAR
600VAR~7800VAR
Resolution
L
0.1VAR
H
1VAR
Calculated
Formula
L
A VAR + B VAR + C VAR
H
Crest Factor
Range
N/A
Resolution
Accuracy
Single-phase
mode(1Ø2W)
Setting (Option)
Voltage(*3)
Range
5~300VAC, 150/300V Auto Range
Resolution
0.1V
Accuracy
±(0.2% of setting + 3counts)
Frequency
Range
40~1000Hz Full Range Adjust
Resolution
0.1Hz at 40.0~99.9Hz , 1Hz at 100~1000Hz
Accuracy
±0.03% of setting
Starting& Ending
Phase Angle
Range
0~359∘
Resolution
1∘
Accuracy
±1∘(45~65HZ)
Current Hi Limit
(OC Fold=OFF)
OC Fold Back
(OC Fold = ON)
0V~150V
0.10~27.60A
0.10~55.20A
0V~300V
0.10~13.80A
0.10~27.60A
Resolution
0.01 Amps
Accuracy
± (2.0% of setting + 2 counts)
OC Fold Back Response Time
< 1.4S
Ramp-Up Timer
(second) (*4)
Range
0.0~999.9s
Resolution
0.1s
Accuracy
± (0.1% + 0.05 sec)
22
)()(

+ QW
