IKONIX apt 400XAC Series User Manual

20
Ramp-Down
Timer (second)
(*4)
Range
0.0~999.9s
Resolution
0.1s
Accuracy
± (0.1% + 0.05 sec)
Delay Timer (*4)
Range
0.5s~999.9s
0.1m~999.9m
0.1h~999.9h
Resolution
0.1(s,m,h)
Accuracy
± (0.1% + 0.1 sec)
Dwell Timer (*4)
Range
0, 0.5s~999.9h (0=continuous)
Resolution
0.1(s,m,h)
Accuracy
± (0.1% + 0.1 sec)
Single-phase
mode(1Ø2W)
measurement
(Option)
Frequency
Range
0.0~1000Hz
Resolution
0.1Hz
Accuracy
±0.1Hz (501~1000Hz Accuracy ±0.2Hz)
Voltage
Range
0.0~420.0V
Resolution
0.1V
Accuracy
± (0.2% of reading + 3counts)
Current(r.m.s) (*5)
Range
0.05A~39.00A
0.05A~78.00A
Resolution
0.01A
Accuracy
± (1% of reading +5counts) at 40.0~500Hz
± (1% of reading +5counts) at 501~1000Hz
and CF<1.5
※Current (peak)≦82.8A
± (1% of reading +5counts) at 40.0~500Hz
± (1% of reading +5counts) at 501~1000Hz
and CF<1.5
※Current (peak)≦165.6A
Current(peak) (*5)
Range
0.0A~114.0A
0.0A~228.0A
Resolution
0.1A
Accuracy
± (1% of reading + 5counts) at 40.0~70.0Hz
± (1.5% of reading + 10counts) at 70.1~500Hz
± (1.5% of reading + 10counts) at 501~1000Hz and CF<1.5
Power (*5)
Range
0W~3900W
0W~7800W
Resolution
1W
Accuracy
± (2% of reading +5 counts) at 40.0~500Hz and PF>=0.2
± (2% of reading +15 counts) at 501~1000Hz and PF>=0.5
