IKONIX apt 400XAC Series User Manual

21
Power Factor
Range
0 - 1.000
Resolution
0.001
Calculated
Formula
W / VA
Power Apparent
(VA)
Range (*15)
0VA~3900VA
0VA~7800VA
Resolution
1VA
Calculated
Formula
V×A
Power Reactive
(Q) (*13)
Range (*15)
0VAR~±3900VAR
0VAR~±7800VAR
Resolution
1VAR
Calculated
Formula
(*14)
Crest Factor
Range
0 - 10.00
Resolution
0.01
Calculated
Formula
Ap / A
Poly-phase
mode(1Ø3W) for
per phase output
setting (Option)
Voltage(*3)
Range
5~300 VAC (phase), 10~600 VAC (line), 150/300V Auto Range
Resolution
0.1V
Accuracy
±(0.2% of setting + 3counts)
Frequency
Range
40~1000Hz Full Range Adjust
Resolution
0.1Hz at 40.0~99.9Hz , 1Hz at 100~1000Hz
Accuracy
±0.03% of setting
Starting& Ending
Phase Angle
Range
0~359∘
Resolution
1∘
Accuracy
±1∘(45~65HZ)
Current Hi Limit
(OC Fold=OFF)
OC Fold Back
(OC Fold =
ON)(*9)
0V~150V
0.01~9.20A
0.01~18.40A
0V~300V
0.01~4.60A
0.01~9.20A
Resolution
0.01 Amps
Accuracy
± (2.0% of setting + 2 counts)
OC Fold Back Response Time
< 1.4S
Ramp-Up Timer
(second) (*4)
Range
0.0~999.9s
Resolution
0.1s
Accuracy
± (0.1% + 0.05 sec)
Ramp-Down
Timer (second)
Range
0.0~999.9s
Resolution
0.1s
