Range: 0-9 ;0=OFF, 1 is softest volume, 9 is loudest volume.
240 x 64 dot resolution Monographic LCD /Contrast 9 Levels 1-9
0=Continuous, OFF, 2~9999
On/Off , Setting On when output current over setting Hi-A value it will fold back output
voltage to keep constant output current is setting Hi-A value, Response time <1400ms
URP Card for standard. Ethernet, GPIB.
430(W) x 400.5(H) x 500(D) mm
Why use the term “Counts”?
Associated Power Technologies publishes some specifications using COUNTS
which allows us to provide a better indication of the tester’s capabilities across
measurement ranges. A COUNT refers to the lowest resolution of the display for
a given measurement range. For example, if the resolution for voltage is 1V then
2 counts = 2V.
Measurement Considerations
1. The peak capacity of the instrument may vary from 3 to 4 times the max rated
current dependent on output voltage. Please refer to the following chart :
