9.7 Software Calibration Procedure
The software calibration is recommended to be performed after the hardware
verification and hardware calibration has been completed.
Required Measurement Standard
• 0-40 Amp AC True RMS Ammeter
• 0-300 VAC True RMS Voltmeter
Required Measurement Equipment
430XAC
• 112 Ω Resistor, 0.9A AC
• 12 Ω Resistor, 9A AC/12.7 Apeak
430XAC SmartConfig
• 56 Ω Resistor, 1.8A AC
• 60 Ω Resistor 18A AC/25.4 Apeak
DC
• 23 Ω Resistor, 4.5A DC
• 8 Ω Resistor 14A DC
460XAC
• 56 Ω Resistor, 1.8A AC
• 60 Ω Resistor, 18A AC/25.4 Apeak
460XAC SmartConfig
• 28 Ω Resistor, 3.6A AC
• 3 Ω Resistor, 36A AC/50.9 Apeak
DC
• 12 Ω Resistor, 9A DC
• 4 Ω Resistor, 28A DC
