parameters.
If you press the Keypad soft key the display will show the text Voltage = above
the voltage meter on the left hand side of the display. A shaded black box (■) will
be flashing waiting for a voltage value to be entered from the numeric keypad.
Once the value has been typed into the instrument you must press the Enter soft
key to accept the value. The Esc soft key is available to exit out of this mode and
move back to the test screen.
The Rotary Knob on the front panel also becomes active. To adjust the voltage
rotate the knob either clockwise or counterclockwise. Clockwise rotations will
increase the voltage, whereas counterclockwise rotations will decrease the
voltage. If LOCK is set to ON, the Rotary Knob is disabled.
