91
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
Indoor unit data
MAGIS COMBO 4
PLUS V2
MAGIS COMBO 6
PLUS V2
MAGIS COMBO 9
PLUS V2
Dimensions (Width x Height x Depth) mm 440x787x400
Maximum heating temperature °C 83
Adjustable central heating temperature (max operating
eld)
°C -25.. 35
Cooling adjustable temperature (max. operating eld) °C 10-40
Domestic hot water adjustable temperature °C 10-65
Domestic hot water adjustable temperature with DHW
integration resistance (optional)
°C -
Water content l 3,1
Expansion vessel volume l 8
Expansion vessel pre-charged pressure bar 1
Hydraulic circuit max. operating pressure bar 3
Head available with 1000 l/h ow rate kPa (m c.a.) 54,0(5,5)
Electrical connection V/Hz 1P, 230Vac, 50Hz
Absorption without additional loads W 160
System integrative resistance absorption (optional) kW -
Maximum relay current for zone pumps (inductive
load)
A1
EEI value - ≤ 0.20 - Det. 3
Equipment electrical system protection - IPX4D
Ambient operating temperature range °C -5 ÷ +40
Ambient operating temperature range with antifreeze
kit (optional)
°C -15 ÷ +40
Empty outdoor unit weight kg 46,5 73,0
Full outdoor unit weight kg 49,5 81,5
Outdoor unit - Ambient operating temperature range.
MAGIS COMBO 4
PLUS V2
MAGIS COMBO 6
PLUS V2
MAGIS COMBO 9
PLUS V2
Room temperature in cooling mode °C 10-40
Room temperature in central heating mode °C -25.. 35
Domestic hot water room temperature °C -25.. 40
Domestic hot water room temperature with DHW
integration resistance (optional)
°C -
