90
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
4
TECHNICAL DATA
4.1 VARIABLE HEAT OUTPUT
e data below refer to the pairing between indoor unit and out-
door unit.
MAGIS COMBO 4
PLUS V2
MAGIS COMBO 6
PLUS V2
MAGIS COMBO 9
PLUS V2
Nominal data for low temperature applications (A7/W35) *
Nominal central heating output kW 4,40 6,00 9,00
Absorption kW 0,85 1,22 1,87
COP kW/kW 5,20 4,92 4,81
Nominal data for low temperature applications (A35/W18) *
Nominal cooling output kW 5,00 6,50 8,70
Absorption kW 1,09 1,47 2,11
EER kW/kW 4,59 4,42 4,12
Nominal data for intermediate temperature applications (A7/W45) **
Nominal central heating output kW 4,20 5,40 8,60
Absorption kW 1,03 1,51 2,33
COP kW/kW 4,08 3,58 3,69
Nominal data for intermediate temperature applications (A35/W7) **
Nominal cooling output kW 3,60 4,70 6,50
Absorption kW 1,11 1,44 1,95
EER kW/kW 3,24 3,26 3,33
Nominal data for medium temperature applications (A7/W55) ***
Nominal central heating output kW 3,90 4,80 8,00
Absorption kW 1,32 1,81 2,73
COP kW/kW 2,95 2,65 2,93
* Central heating mode status: heat exchanger water inlet/re-
mains at 30 °C/35 °C, outdoor air temperature 7 °C db/6 °C wb.
P e r f o r m a n c e i n c o m p l i a n c e w i t h E N 14 5 11 .
Cooling mode status: heat exchanger water inlet/remains at 23
°C/18 °C, outdoor air temperature 35 °C. Performance in compli-
a n c e w i t h E N 14 5 11 .
* Central heating mode status: heat exchanger water inlet/re-
mains at 40 °C/45 °C, outdoor air temperature 7 °C db/6 °C wb.
Cooling mode status: heat exchanger water inlet/remains at 12
°C/7 °C, outdoor air temperature 35 °C. Performance in compli-
a n c e w i t h E N 14 5 11 .
*** Central heating mode status: inlet/remains at 47 °C/55 °C, out-
door air temperature 7 °C db/6 °C wb. Performance in compliance
with EN 14511.
