Immergas MAGIS COMBO PLUS V2 Series User Manual

97
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
Average temperature table (47/55) average zones
Model MAGIS COMBO 9 PLUS V2
Air/water heat pump yes Low temperature heat pump no
Water/water heat pump no With additional central heating device no
Brine/water heat pump no Mixed central heating device with heat pump: no
e parameters are declared for average temperature application, except for low temperature heat pumps. e parameters for low temperature heat
pumps are declared for low temperature application
 e p a r a m e t e r s a r e d e c l a r e d f o r a v e r a g e c l i m a t i c c o n d i t i o n s
Element Symbol Value Unit Element Symbol Value Unit
Nominal heat output
Pnomi-
nale
8,00 kW
Room central heating seasonal energy
eciency
η
s
128 %
Central heating capacity declared with a partial load and indoor
temperature equivalent to 20°C and outdoor temperature T
j
Performance coecient declared with indoor temperature equivalent to
20°C and outdoor temperature T
j
T
j
= – 7 °C Pdh 7,1 kW T
j
= – 7 °C COPd 1,76 -
T
j
= + 2 °C Pdh 4,3 kW T
j
= + 2 °C COPd 3,32 -
T
j
= + 7 °C Pdh 2,8 kW T
j
= + 7 °C COPd 4,62 -
T
j
= + 12 °C Pdh 2,6 kW T
j
= + 12 °C COPd 5,88 -
T
j
= bivalent temperature Pdh 7,1 kW T
j
= bivalent temperature COPd 1,76 -
T
j
= operating limit temperature Pdh 4,9 kW T
j
= operating limit temperature COPd 1,35 -
for air/water heat pumps:
T
j
= – 15 °C
(se TOL < – 20 °C)
Pdh - kW
for air/water heat pumps:
T
j
= – 15 °C
(se TOL < – 20 °C)
COPd - -
Bivalent temperature T
biv
-7 °C
for air/water heat pumps: Operating limit
temperature
TOL -10 °C
Central heating capacity cycle intervals Pcych - kW Cycle intervals eciency
COPcyc
o
PERcyc
--
Degradation coecient Cdh 0,9 - Water heating temperature operating limit WTOL - °C
D i  e r e n t m o d e o f e n e r g y c o n s u m p t i o n f r o m t h e a c t i v e m o d e A d d i t i o n a l h e a t i n g a p p l i a n c e
OFF mode P
OFF
0,000 kW Nominal heat output Psup 24,00 kW
ermostat mode o P
TO
0,010 kW
Type of energy supply voltage fossil fuelStandby mode P
SB
0,010 kW
Guard heating mode P
CK
0,000 kW
Other items
Capacity control VARIABLE
For air/water heat pumps: nominal air
output to outside
-3960m
3
\h
Indoor/outdoor sound level L
WA
64 dB
For water or brine/water heat pumps:
nominal ow of brine or water, outdoor heat
exchanger
--m
3
\h
Annual energy consumption Q
HE
5054
kWh
or GJ
For mixed central heating appliances with a heat pump
Stated load prole - Water central heating energy eciency η
wh
-%
Daily electrical power consumption Q
elec
- kWh Daily fuel consumption Q
fuel
-kWh
Annual energy consumption AEC - kWh Annual fuel consumption AFC - GJ
Contact information Immergas S.p.A. via Cisa Ligure n.95
