17 Page 17 - 6 Tank Sentinel Setup Programming Guide
Worksheet # 17-3 – Output Groups – Sensor Channels 17 to 24
Fill-in the work sheet below and compare assignments with other work-sheets to
uncover conflicts before programming output devices.
A maximum of
3 alarm Output
Groups ( OG )
can appear per
channel # N...
TSP-DDS &
TSP-DTS
sensors have
3 alarms:
water,
product &
sump full.
Alarm OGs are:
STD (standard)
PROD
(product)
WATER OG
SMP FL
(sump full)
DRY WL
(dry well)
HGH BR (high
brine level)
LOW BR (low
brine level)
VAPOR OG
Write-in all
alarm OG
for each
sensor
channel #.
OG = Output Group
- Out
p
ut Grou
p
Assi
g
nment WORKSHEET Out
p
ut Grou
p
choices -
Sensor Chnl #17:
NONE
A
B
C
Sensor Chnl #18:
D
E
F
G
Sensor Chnl #19:
H
I
J
K
Sensor Chnl #20:
L
M
N
O
Sensor Chnl #21:
P
Q
R
S
Sensor Chnl #22:
T
U
V
W
Sensor Chnl #23:
X
Y
Z
AA
Sensor Chnl #24:
BB
CC
DD
EE
example:
FF
STD OG 221
P
Could activate the annunciator and a ROM relay (output)
to disable dispensin
g
if a li
q
uid is detected
(
standard sensor shown
)
ALL
Output Devices: Modulated Annunciator, Solid Annunciator, Relay 1, Relay 2, I/O Output Module
Channel # 1 to # __ (record all OG Assignments in the vertical column)
