Annunciator Setup Page 14 - 1
14
The annunciator menu must be set (DO NOT skip
this menu). The annunciator
is an Output Device
that produces
an audible alarm to alert attendants
of a problem (flashing warning or alarm lights on
the console also provide visual indications).
Two sounds can be produced: a modulated
(beeping) or a continuous (solid) tone. Any Alarm
Output Group
can be programmed to sound the
annunciator horn.
See Worksheets for applicable Output
Group assignments. Use the Table of
Contents (TOC) to locate Worksheets.
Remember:
•
Push
UP/DOWN
▲
▼ keys to show more
menus or menu selections.
•
Use menu keys
(M1
to
M4)
to access
menus.
•
Press
ENTER
to accept a selection or input a
value into the setup configuration memory.
•
Press
CANCEL
to cancel data entry
Annunciator Time-out
Input a
considerable
alarm time-out
value (i.e. 10 seconds) – especially if
an acknowledge password is required
before an alarm can be silenced. Also
see the Relays Setup Chapter and input
relay time-outs if external alarm
annunciators are used.
14 Annunciator
SETUP PROGRAMMING
Annunciator Menu (Console Alarm Horn)
H U
MENU
× Press this key and follow the
7
highlighted sequence below
Press
DOWN
▼ key twice ( 2 X )
SETUP MENU (MORE)
EXIT SYSTEM TANKS PROBES
!!
NOTE
☞
NOTE
☞
See the Table of Contents to find topics in
this manual. See the Preface for general
information about this manual. And see the
Installation, Operator’s, TroubleShooting
Guides, and Application Notes for other
reference material.
Contents:
Annunciator Menu
Annunciator Timeout
Modulated & Solid Annunciator
Output Groups and Alarm
Assignments
MODULATED ANNUNCIATOR
TIMEOUT
MODULATED ANNUNCIATOR TIMEOUT
0
0 to 3600
Use keypad to input a value.
Press
ENTER
to accept this data.
(Input an automatic time-out / turn-off value in seconds... Ø = no time-out, the
attendant must press
ACK
to silence alarms, 3600 = 60 minutes or 1 hour time-out )
ANNUNCIATORS
MODULATED SOLID TEST
M1 M2 M3 M4
SETUP MENU (MORE)
SCLD TEST CLK/CAL
ANNUNC
RELAYS
M1 M2 M3 M4
SELECT MENU OPTION
SETUP
UPGRADE LANGUAGE DATALOG
M1 M2 M3 M4
To Next Page
