PREFACE Page P - vii

Standard and

Optional

Output Devices

NOTE

Programming

I/O

Module Operation

The TS-CIM / TS-IEM channels * can function either as an input or an output module. The

mode menu option allows selection of the channel operation — this must correspond to the

type of module that is inserted into the channel. Input mode must be selected for input

modules, and output mode must be selected for output modules.

Reference the Chapter

about

IO MODULE

setup programming.

Aux. Inputs are always inputs and cannot be changed because the input circuitry

is hard-wired. Reference the Chapter about

AUX INPUT

setup programming.

Interfacing TS-LLD to Tank Gauge

In order to interface the INCON TS-LLD line leak detector(s) to the TS-1001/504 / 2001/

508 / Tank Sentinel consoles —

Use the

TS-LLD

interface terminals within the console (providing RS-485 bidirectional

communication). The first TS-LLD is wired to the tank gauge and the others are connected

to each other (1 to 2, 2 to 3... ).

LLD

is available with Tank Sentinel software version #

1.10 and higher ( check options – L must be in the part number ).

Standard Output Devices:

Modulated Annunciator

Solid Annunciator

Relay 1

Relay 2

Optional Output Devices:

TS-ROM Relay 1

TS-ROM Relay 2

TS-ROM Relay 3

TS-ROM Relay 4

TS-ROM Relay 5

TS-ROM Relay 6

TS-ROM Relay 7

TS-ROM Relay 8

Optional (TS-CIM / TS-IEM) Output Devices

I/O Module Output 1*

I/O Module Output 2*

I/O Module Output 3*

I/O Module Output 4*

I/O Module Output 5*

I/O Module Output 6*

I/O Module Output 7*

I/O Module Output 8*

I/O Module Output # 9* I/O Module Output # 10*

I/O Module Output # 11* I/O Module Output # 12*

I/O Module Output # 13* I/O Module Output # 14*

I/O Module Output # 15* I/O Module Output # 16*

I/O Module Output # 17* I/O Module Output # 18*

Note

: The TS-2001 will list the

TS-CIM Output Modules as I/0

Module - Output

s # 17 through

24 (if installed).

I/O Module Output # 19* I/O Module Output # 20*

I/O Module Output # 21* I/O Module Output # 22*

I/O Module Output # 23*

I/O Module Output # 24*


