Communication Ports Setup Page 21 - 3
21
COMM PORT 2 Menu
Use COMM PORT 2 for remote connection to
a POS terminal, or external modem, or to a
Computer system / IBM PCs (this may
require a null modem cable).
Go back to display this menu and press
M2
to access the Comm Port 2 menu.
COMM PORT 2
MODE Press
M1
key.
COMMUNICATIONS MODE
NATIVE
Use
UP/DOWN
▲
▼ keys to show choices.
VEEDER ROOT Press
ENTER
to accept this data.
BAUD Press
M2
key.
BAUD RATE
9600 BAUD
Use
UP/DOWN
▲
▼ keys to show choices.
300 BAUD Press
ENTER
to accept this data.
:
19,200 BAUD
DATA BITS Press
M3
key.
DATA BITS
8 BITS
Use
UP/DOWN
▲
▼ keys to show choices.
7 BITS Press
ENTER
to accept this data.
STOP BITS Press
M4
key.
STOP BITS
1 STOP BIT
Use
UP/DOWN
▲
▼ keys to show choices.
2 STOP BITS Press
ENTER
to accept this data.
— Press the
DOWN
▼ key to show more menu items —
PARITY Press
M1
key.
PARITY
NO PARITY
Use
UP/DOWN
▲
▼ keys to show choices.
ODD PARITY Press
ENTER
to accept this data.
EVEN PARITY
ECHO TEST Press
M2
key.
ECHO TEST ACTIVE…
HIT ANY KEY TO QUIT
—
CONTINUED
ON
THE
NEXT
PAG E
—
ACCESS CODE or PHONE No. AT Command
Characters:
D = (
,
) comma = dial delay
NOTE
☞
Cycle console power on and off after
programming is done, or after any COM
PORTS setting is changed. Also, when the
data / fax modem is present, press
CHECK
&
M3
DIALTONE to see if a dial
tone is detected.
COMM PORTS
COMM 1
COMM 2
FAX/MODEM*
M1 M2 M3 M4
To Next Page
