TS-TPI Setup Programming Page 23 - 3
23
The number displayed represents the number of
pump controllers that the TPI device has detected,
therefore, it is also the number of pumps.
The data on display (“2”) was generated from Auto
- Configuration. This is a ‘READ ONLY’ field. The
data cannot be edited.
Number of Pumps Menu
The number of pumps information is displayed
under the SYSTEM menu.
Return to the main SETUP MENU display,
which shows ....
NOTE
☞
NUMBER OF PUMPS READ ONLY
2
READ ONLY NOTE
Fields that display the words “READ ONLY” in the
upper right corner have been automatically updated
by the Auto-Configuration process. These fields are
not editable. The next Auto-Configuration process
will over-write these fields and values.
SETUP INFO (MORE)
NO. LINES NO. SENS NO. PUMPS
M1 M2 M3 M4
NO. PUMPS “READ ONLY”
Here is the main SETUP MENU display.
Press the
M2
key to display the SYSTEM menu.
Press the
DOWN
▼ key to until NO.PUMPS is
displayed ....
Here is the SETUP INFO display.
Press the
M3
key to display the number of
pumps information ....
— Press the CANCEL key twice, to return to the SETUP MENU menu —
— Proceed to the Pump N Menu(s) section, which is described on the next page —
