Incon task sentinel TS-508 User Manual

29 Page 29 - 2 Tank Sentinel Setup Programming Guide
NOTE:
Dia
g
nostic text
in the left column, is shown
bolded
{
become alarms if active for 48 hours
}
#
Printed / Faxed / Displayed
Alarm / Warning Text:
Alarm Type:
System WARNING / Error Descriptions and
ALARM Descriptions
(actions to take)
8
LINE OUT OF COMPLIANCE LINE
33 or more days have passed since a 0.2 gph line
leak test has finished and passed
(prevent
dispense attempts until the monthly test passes)
9
LSU COMM/LSU COMM
FAILURE
LINE
(Push RESET / TEST button on the TS-LLD
control unit that is flashing an 83 Alarm-error code
and call for service).
10
LSU FAIL/LEAK SENSING
UNIT FAIL
LINE
(Push RESET / TEST button on the TS-LLD
control unit that is flashing an 81 Alarm-error code
and call for service).
11
ACKNOWLEDGED message A
warning
or
alarm
has been ACKNOWLEDGED
12
ACTIVE message An ACTIVE Alarm or Warning exists
13
CLEARED message Formerly active Alarm or Warning has cleared
14
LEAK TEST: ABORTED
RESULT
message Leak Test was aborted for Tank N
15
LEAK TEST: FAILED
RESULT
message
- Slope is less / more negative than the leak
threshold for Tank N
(see LEAK above - Retest &
See Chapter 3 & 4)
16
LEAK TEST: INCREASE
RESULT
message
+Slope is more positive than the leak threshold
value (= leak test/2) for Tank N
(see LEAK,
Retest and See Chapter 3 & 4)
17
LEAK TEST: PASSED
RESULT
message Slope is less than leak threshold for Tank N
18
LEAK TEST: INDETERMIN
RESULT (indeterminate)
message
The leak test ran 8 hours but still can't determine a
result for Tank N
(some disturbance affected the
test... try again but wait 2 hours after the last
dispense, or 6 hours after the last delivery).
19
SENSOR FAIL / SNS FAIL /
SEN FAL
message Proceeds Sensor Fail Alarm reports
20
SYSTEM FAIL message Proceeds System Alarm Warning reports
21
TEST FAILED message
A Leak Test Failed result - for Tank and/or Line N
alarm report
22
TRANSIENT message
Brief Alarm or Warning that clears quickly /
automatically
23
AUXILIARY INPUT SENSOR
Auxiliary input detected on channel 1 or 2
(follow
policy procedure at your site).
24
CPM LOW CURRENT SENSOR
Current of Rectifier dropped below the threshold
value (a Tank Sentinel setting) (follow policy
procedure at your site)

Incon task sentinel TS-508 Specifications

General

Brand	Incon
Model	task sentinel TS-508
Category	Measuring Instruments
Language	English
