6 | Operation INFICON
76 / 108 XL3000flex-Operating-instructions-jina83en1-07-(2105)
Fig.7:
I/O module (2): Visualized information to the digital inputs
1 Input signal condition 2 Configured function (INV =
Function is inverted)
3 Status of the function (active or
inactive)
I/O module (3): Visualized information to the digital outputs
