RS232 Protocol Function List
Baud Rate:19200
Parity Bit: None
Data Bit: 8
Stop Bit: 1
Lamp Ignition delay = 20s
Power Down delay = 10s
Source change delay = 8s
Intercommand delay minumum = 5ms
Intercharacter delay minumum = 2ms
Power return code (ok)
Status ? (PWR?) (0-1,n) n=0,1
ON
(PWR1)
OFF
(PWR0)
ON & return (PWR1!) (0-1,1)
OFF & return (PWR0!) (0-1,0)
Blank Key return code (ok)
Status ? (BLK?) (0-1,n) n=0,1
ON (BLK1)
OFF (BLK0)
ON & return (BLK1!) (0-1,1)
OFF & return (BLK0!) (0-1,0)
Source return code (ok)
Status ? (SRC?) (0-22,n) n=0-22
Computer1 (SRC0)
VIDEO (SRC11)
HDMI1 (SRC4)
HDMI2 (SRC5)
HDMI3 (SRC6)
Computer1 & return (SRC0!) (0-22,0)
VIDEO & return (SRC11!) (0-22,11)
HDMI1 & return (SRC4!) (0-22,4)
HDMI2 & return (SRC5!) (0-22,5)
HDMI3 & return (SRC6!) (0-22,6)
