Installation Manual
General information 9
Chapter 2
General information
2.1 Documentation supplied
• Installation manual (this manual)
• Programming Manual
• User's Manual
The manuals are supplied with the device. For further copies of the Installation Manual, please contact
INIM ELECTRONICS offices quoting the order number shown in Appendix C .
2.2 Manual details
Title: SmartLoop Installation Manual
• Edition, Issue: 1.01
• Month and Year of printing: April 2007
• Installation Manual Code: DCMIINE0SLOOP
2.3 About the Software
• SmartLeague software version: 2.0.x
• SmartLoop Firmware Version: FWINI0SL0PAA00 1.00
• SmartLoop Loop Driver Firmware Version: FW0000LOOPDRV 1.00
• SmartLoop Frontplate Firmware Version: FW0000SLEDKBD 1.00
• SmartLAN Firmware Version: FWIN00SLAN 1.00
• SmartLoop/PSTN Firmware Version: FW0000SLPSTN 1.00
• SmartLoop/INOUTFirmware Version: FW0000SLIO 1.00
• SmartLetUSee/LCD Repeater Firmware Version: FW0000SLEDKBD 1.00
• SmartLetUSee/LED Repeater LED Expansion Firmware Version: FW0000SLLED 1.00
2.4 Addressees
• Installer
• Technical assistance
2.5 Operator authorization—access levels
Level 1
All building occupants can view the system status (active events) and events log and silence the panel
beeper.
Level 2
ONLY authorized keyswitch users and PIN users (5 digit codes) can Enable/Disable loop devices, bell
outputs, software zones and network devices, and SILENCE or RESET the system.
Level 3
ONLY authorized technicians, appointed by the Installer company can, by means of a screw driver,
remove the screws and open the fire control panel cabinet to insert the J2 Jumper and then, after
entering a 5 digit PIN (5 digit code) access the parameter programming phase and/or carry out
maintenance work (for example, change the battery, replace fuses, etc.).
