Installation and programming manual
Programming fire detection points 47
11.1.3 Signals emitted by the point (Input)
Verify For detectors only.
YES
If the device value exceeds the set threshold, the panel will not generate an instant but will
wait to see if the device values exceed the threshold again within the pre-set time (refer to
paragraph 9.2 - Setting delays and times). If the device value exceeds the set threshold
again, the panel will generate an alarm, otherwise, it will restore to standby.
NO If the device value exceeds the set threshold, the panel will generate an instant alarm.
Alarm YES If the analysis value exceeds the alarm threshold (refer to paragraph 11.1.2), it will
generate an alarm signal to the panel, trigger an alarm on the zone it belongs to
(primary zone) and activate the associated outputs. The point cannot be used for
Monitoring purposes.
NO If the analysis value exceeds the alarm threshold, it will send an alarm signal to the
panel, but will not trigger an alarm on the zone it belongs to (primary zone) or activate
its associated outputs. If alarm events do not require signal transmission to the panel,
select Monitor as the activation signal.
Pre-alarm YES If the analysis value exceeds the alarm threshold, it will send a pre-alarm signal to the
panel and trigger the pre-alarm time of the zone it belongs to. When the pre-alarm time
expires, it will generate an alarm on the zone it belongs to (primary zone) and activate
its associated outputs. The point cannot be used for Monitoring purposes.
NO If the analysis value exceeds the alarm threshold, it will send an alarm signal to the
panel, without activating the pre-alarm time.
Fault YES If one of the possible faults occurs on the input (refer to Chapter 17 - Diagnostics and
fault solutions), it will send a fault signal to the panel and generate a fault on the zone it
belongs to (primary zone).
NO Faults that occur on the input will be ignored.
Warning YES If the analysis value exceeds the warning threshold, it will send a warning signal to the
panel and the respective zone.
NO If the analysis value exceeds the warning threshold, the event will be signaled on the
panel but not on the zone.
Monitor YES If the analysis value exceeds the alarm threshold, it will send a 'Monitor' signal to the
panel and activate all the associated zone outputs.
Attention: Enablement of the Monitor signal inhibits the Alarm and Pre-
alarm signals. If an input is programmed as 'Monitor', it will be
unable to emit Alarm and Pre-alarm signals.
NO The point will operate as an alarm point.
Actions EXAMPLE: keyswitch that controls specific zones. Only for detectors with the "ON-OFF" option.
Disable
zone
YES Only for detectors with the "ON-OFF" option. Activation of the point bypasses the
selected zone or zones.
Test zone NO Only for detectors with the "ON-OFF" option. Activation of the point generates test
conditions on the selected zone or zones.
Night
prealarm
Enable or disable the pre-alarm time during night mode.
For example, buildings closed during the night do not require pre-alarm signaling.
Monitor
restore
YES
Only for the Monitor input. The outputs will restore to standby when alarm conditions clear.
EXAMPLE: The value exceeds the temperature threshold and thus activates a fan. When the
temperature value returns to normal, the detector should stop signaling.
NO
Only for the Monitor input. If alarm conditions clear, the outputs will remain active.
EXAMPLE: The cooling system continues working until it is switched off manually.
Filtered YES After a re-arm operations, the control panel will ignore the point concerned for the set
Filter time
NO After a re-arm operations, the control panel will not ignore the point concerned.
