48 Programming fire detection points
Installation and programming manual
11.1.4 Signals that activate the output
Note: Some of the parameters do not apply to certain devices. Accidental programming will not interfere with
the panel functions.
Alarm YES
The output will activate when at least one of its assigned zones goes into alarm status. A zone will
generate an alarm when at least one of its input points goes into alarm status.
NO The output status will remain unchanged even if one of its assigned zones goes into alarm status.
Pre-alarm YES The output will activate when at least one of its assigned zones goes into pre-alarm status. A zone
will generate a pre-alarm when at least one of its input points goes into pre-alarm status.
NO The output status will remain unchanged even if one of its assigned zones goes into pre-alarm
status.
Fault YES The output will activate when at least one of its assigned zones signals fault status. A zone will
generate a fault when at least one of its input points signals fault status.
NO The output status will remain unchanged even if one of its assigned zones signals fault status.
Warning YES The output will activate when one at least one of its assigned zones goes into early-warning
status. A zone will generate an early warning when at least one of its input points goes into early-
warning status.
NO The output status will remain unchanged even if one of its assigned zones goes into early-warning
status.
Monitor YES The output will activate when at least one of its assigned zones goes into Monitor status. A zone
will go into Monitor status if an input point goes into Monitor status.
NO The output status will remain unchanged even if one of the assigned zones goes into Monitor
status.
Disable YES The output will activate when at least one of its assigned zones is bypassed.
NO The output status will remain unchanged even if one of the assigned zones is bypassed.
Double
alarm
YES The output will activate when at least two points assigned to the specified zones go into alarm
status.
NO The output will activate when at least one of the specified zones goes into alarm status.
Primary
Zone
XX Number of a zone that activates the output. Successive zone group option = YES, the number of
the first zone in the group.
00 The output will activate when at least one of the system zones activates, that is, when the Alarm
NAC output (Panel Alarm) is active.
Secondary
Zone
XX Number of another zone that activates the output Successive zone group option = YES, the
number of the last zone in the group.
-- The output can be activated by the primary zone only.
Zone group YES The output activates when one of the zones in the zone group activates (i.e. between the Primary
zone and Secondary zone).
NO The output will activate when either one of the two zones indicated activates.
Point echo YES The output activates even if the input point is active.
NO The output will activate only when one of the signals selected under “Output-----” occurs.
For example, an external LED outside a hotel room which replicates the status of the detector
located inside.
Silenceable YES
The output can be silenced (switched Off) by the SILENCE button on the panel.
NO The output cannot be silenced. Any SILENCE commands will be ignored.
Reset echo YES The output will activate after Reset.
Duration Output activation time
Equation Number of the equation that activates the output.
