Installation and programming manual
Argus Devices 65
B.2 Device Bases
B.3 Wireless devices
VMCZ100 Conventional line interface module Interfaces conventional devices to the loop
VMIC404 Module with 4 inputs and 4 outputs Module with 4 supervsed inputs and 4 outputs (dry contact)
VLS100 Intelligent Wall Sounder Loop Powered Sounder
VWLS100 Weatherproof Intelligent Wall Sounder Loop-powered sounder for outdoor installation
VLS100-AV Intelligent Wall Sounderflasher Loop-powered sounderflasher
VWLS100-AV
Weatherproof Intelligent Wall Sounderflasher Loop-powered sounderflasher for outdoor installation
VLBE100 Intelligent Flasher Loop Powered beacon
VTAO10 Sounderflasher fire sign Visual/Audible warning sign with input/output module
VTAOA10 Self-powered sounderflasher fire sign Self-powered visual/audible warning sign with input/output module
VFI100 Intelligent remote indicator Remote addressable alarm repeater
VPU100 Programmer Allows fast addressing of Argus series devices
a. Configured as “Rate-of-rise detector” at default (alarm is triggered by rapid rise in temperature or when the temperature
exceeds the 54°C alarm threshold). To configure as “High temperature detector” ( Rate-of-rise feature bypassed and
fixed temperature set at 70°C) use the VPU100 programmer. The panel will recognize the configuration criteria automati-
cally.
Model Name Description
VB100 Base Standard base for VEGA detectors
VDBS100 Deep Standard Base Allows connection to wall-mount cable runs
BLR100 Relay Base Relay activated by the detector R output attached to the base
VBS100 Base with Sounder Activated by the detector R output attached to the base
VBLS100 Base with addressable sounder Occupies a loop address
Model Name Description
VW2W Wireless translator Connected to Loop, 32-device interface (Sagittarius series -
SG) wireless to panel
The panel sees the 32 devices as if they were connected to
the Loop (with different addresses)
SGWE Wireless expansion
SG100 Wireless analogue smoke detector
SG200 Wireless analogue smoke and heat detector
SG350 Wireless heat detector
(
a
)
a. Configured as “Rate-of-rise detector” at default (alarm is triggered by rapid rise in temperature or when the temperature
exceeds the 54°C alarm threshold). To configure as “High temperature detector” ( Rate-of-rise feature bypassed and fixed
temperature set at 70°C) use the VPU100 programmer. The panel will recognize the configuration criteria automatically.
SGRBS100 Wireless sounder base
SGRBS100-AV Wireless sounder base with beacon
SGMI100 Wireless input module
SGMC100 Wireless output module
SGMCB100 Wireless module with 2 outputs
SGCP100 Wireless callpoint
SGRS100 Wireless sounder
SGVA100 Wireless voice announcer
SGFI100 Wireless addressable remote alarm repeater
