Setup
This opens a dialogue for some settings that are usually just made once and that
are rarely changed.
Setup – General Description
In this dialog some annotation can be
set that will be stored within the rec-
orded data:
ship’s name and
travel ID
There is a checkbox to enable an auto-
matic increment of the profile number
with each record start.
!
Please note the length for the annotation strings (ship name, travel ID)
is limited to 20 characters.
Setup – Ping Rate Settings
If required the ping rate can be limited
manually. The default “System Con-
trolled” ensures the ping rate () to be
kept as high as possible:
≈
750
+ + 7.5
(RS – range start; RL – range length)
Please see section 4.9.6 on page 45 for
details.
Setup – Gain Definition Sub-Bottom
This sets the increments for the gain
controls (range 1–6dB). A good value
would be an increment of 2 or 3dB.
The auto gain function is set up here as
well.
Please see section 4.9.4 on page 44 for
details.
This item is not available with the
INNOMAR “smart” model.
