Inovance CS200 User Manual

Chapter 5 Function Code Table
- 67 -
Function
Code
Parameter Name Function Description Setting Range Default
b7.02
Brake release
frequency in the
downward direction
For the use, refer to the descriptions of b6.02 to
b6.06. The function is active only when b7.01 = 1
and the elevator runs in the downward direction.
Min. frequency
(b1.03) to
20.00 Hz
0.00 Hz
b7.03 Brake release current
in the downward
direction
0.0% to
150.0%
0.0%
b7.04 Brake release time
in the downward
direction
0.00s to 5.00s 0.00s
b7.05 Brake apply frequency
in the downward
direction
Min. frequency
(b1.03) to
20.00 Hz
2.00 Hz
b7.06 Brake apply time
in the downward
direction
0.00s to 5.00s 0.20s
b7.07 Up limit stop mode They are used to select the stop mode when the
limit switch acts.
0: Quick stop
1: Coast to stop
2: Decelerate to stop
0 to 2 0
b7.08 Down limit stop mode 0
b7.09 Forbid running stop
mode
0
b7.10 Selection of weighing
sensor input channel
It is used to select the AI for input of the weighing
sensor signal.
0: Weighing function disabled
1: AI1
2: AI2
0 to 2 0
b7.11 Overload threshold If the current load weight (U0.08) obtained by the
AC drive after calculation is larger than the value of
this parameter, the drive running is forbidden.
0.00 to 9.99
tons
2.20
tons
